Unlock the Power of Precision with Super High-Speed Cameras
Kron Technologies’ Chronos cameras bring ultra high-speed imaging within reach—capturing up to 21,000 fps with crisp detail and ease. Designed for engineers, researchers, and industrial users, these cameras offer plug-and-play simplicity, built-in storage, and intuitive touchscreen controls. Whether you're analyzing high-speed machinery, fluid dynamics, or impact testing, Chronos cameras deliver reliable, high-quality results without the complexity or cost of traditional high-speed systems.
All Chronos cameras come with larger sensor formats of 2/3″ and 4/3″ with larger pixel size of 4.5um to 10um with high throughput of 1.4Gigapixels to 11.8Gigapixels per second.
All Chronos models operate at a minimum of 1000 fps at full resolution. With lower resolutions, the 2/3″ sensor can operate at 40,413 fps and 4/3″ can operate at 29,002 fps.
The Chronos cameras offer flexible RAM options of 8GB, 16GB, 32GB and 128GB, enabling recording times ranging from 3 to 16 seconds, depending on the model.
Chronos cameras support uncompressed video format CinemaDNG Raw, and Tiff Raw for images. Uncompressed formats – H.264, H.265, AVC, HEVC, and MPEG-4 file format.
Chronos cameras support multiple recording methods such as Standard, Segmented, Gated Burst and Live Slow Motion offer versatile image capture options for dynamic environments.
Offers range of passive, field-swappable lens mounts designed for perfect integration with Chronos cameras. Supported mounts & adapters are C, MFT, F, E, PL and EF Mount.
Authorized Distributor for Krone in India
Application Areas
Academic & Research: Universities and labs use high-speed cameras to capture fast physical events like impacts, combustion, and fluid motion—helping validate models and deepen scientific understanding.
Aerospace & Defence: These cameras are crucial for analyzing high-velocity tests, structural integrity, and explosive events—enabling safer, more efficient development of defence and aerospace systems.
Media Production: High-speed imaging adds dramatic slow-motion effects in commercials, films, and documentaries, offering directors precision and creative flexibility in post-production.
Sports & Biomechanics: In sports science and medical fields, high-speed footage is used to analyze movement, prevent injuries, and enhance performance through detailed motion breakdowns.
Fluid Dynamics: From spray nozzles to HVAC systems, industries use high-speed imaging to study flow behavior, turbulence, and cavitation—supporting better product design and process efficiency.
Product Name
Product Name
Product Name
Product Name
Product Name
Product Name
Product Name
High Speed Imaging and Its Applications
Motion Analysis in Sports
Ballistics & Combustion
Vibration Analysis in Machines
Material Testing
Chemical Reaction Analysis
Schlieren Imaging & Flow Analysis
| Camera | Chronos 1.4 | Chronos 2.1-HD | Chronos 4K12 | ||
|---|---|---|---|---|---|
| Maximum Resolution | 1280 x 1024, at 1069 FPS | 1920 x 1080 (HD) at 1000 FPS | 4096 x 2160 (4K) at 1397 FPS | ||
| Format | 2/3" | 4/3" | 4/3" | ||
| Pixel Size | 6.6μm | 10μm | 4.5μm | ||
| Minimum Resolution | 320 x 96, at 40,413 FPS | 640 x 96, at 24,046 FPS | 128 x 32, at 29,002 FPS | ||
| Throughput | 1.4 Gigapixels Per Sec | 2.1 Gigapixels Per Sec | 11.8 Gigapixels Per Sec | ||
| Memory Options | 8 GB, 16 GB, 32 GB | 8 GB, 16 GB, 32 GB | 128 GB | ||
| Sensitivity (ISO), Color Sensors | 320 - 5120 | 500 - 8000 | 100, 150, 200, 400 | ||
| Sensitivity (ISO), Mono Sensors | 740 - 11840 | 1000 - 16000 | 200 - 800 | ||
| Shutter Type | Global Electronic | Global Electronic | Global Electronic | ||
| Shutter Duration | 1/FPS to 1μs, (1/1,000,000s) | 1/FPS to 10μs, (1/100,000s) | 1/FPS to 1μs, (1/1,000,000s) | ||
| Standards Lens Mount | CS/C Mount | CS/C Mount | Universal Plate | ||
| Focus Aid, Peaking, Over Exposure Indicator (Zebras), Gain, Color Temp / White Balance, Text Overlays | Yes | Yes | Yes | ||
| 1:1 Viewfinder Zoom on LCD, Color Matrix | Yes | Yes | - | ||
| Histogram | - | - | Yes | ||
| Save to External Media | Yes | Yes | Yes | ||
| Save to Network Drive | Yes | Yes | Yes | ||
| On-Camera Review | Play / Pause / Mark-Start / Mark-End | Play / Pause / Mark-Start / Mark-End | Play / Pause / Mark-Start / Mark-End | ||
| Cooling System | Single Fan | Single Fan | Dual Fan | ||
| Weight | 1.06 kg (2.34 lbs) | 1.06 kg (2.34 lbs) | 1.32 kg (2.91 lbs) | ||
| Operating | -20 °C to +40 °C | -20 °C to +40 °C | 0 °C to +40 °C | ||
| Temperature | (-4 °F to +104 °F) | (-4 °F to +104 °F) | (32 °F to +104 °F) | ||
| Network Video Streaming | Yes | Yes | Yes | ||
| Request Quote | Request Quote | Request Quote |
Request a Quote
Discover the ideal machine vision camera for your specific needs, with solutions tailored to your application and budget. Get expert guidance and pricing today.
